16 Channel Mixing Desk With USB Playback

by: Redback
SKU: A2652
This compact high performance desk mixer is ideal for live/stage sound mixing in small applications such as theatre, bands, function centres and venues.
$308.18

All Prices Shown are (ex GST)
Bulk Pricing
ea $308.18
2+ $280.91
i h

Overview

A lightweight and compact USB powered mixer featuring 16 channels. Channels 1 to 6 are XLR/6.35mm combo sockets suitable for both mic and line level signals. Channels 7 to 10 are 6.35mm L/R mono jack inputs. Channel 11 and 12 is a stereo RCA input. Channel 13 and 14 is a stereo 3.5mm jack input. Its an ideal mixing solution for small to medium venues. An additional input is provided via Bluetooth audio streaming from your device. Being USB powered it is very portable and easy to power.

A dedicated slider is provided for DSP effects level, Aux return level, master volume, each with AFL control and Aux send on DSP.

Channels 1-6 are identical and feature: • signal presence indicator • gain adjustment with low cut on/off • high, mid and low adjustments • aux input level adjustment • fx level adjustment • pan L/R control • PFL button • volume control.

Channels 7-10 are identical and feature: • signal presence indicator • gain adjustment • high, mid and low adjustments • aux input level adjustment • fx level adjustment • pan L/R control • PFL button • volume control.

Remaining channels and Bluetooth channel each feature adjustable volume control and aux send button.



Features:

  • All inputs top mounted for easy access
  • Combo XLR and 6.35mm jack inputs on channels 1-6
  • Bluetooth audio receiver
  • 24 bit 48KHz DSP effects with preset adjustment and level
  • Adjustable aux return level
  • USB MP3 recording and playback
  • LED VU meter
  • Monitor & phones outputs
  • Aux send and return
  • Foot switch input
  • 48V phantom power





Specifications:

Mic Maximum Input Level: +10dBu

Line Maximum Input Level: +22dBu

XLR Maximum Output Level: +22dBu

TRS Maximum Output Level: +20dBu

Master meters: 6 segment - 20dB to peak

Channel Meters: 1 LED signal indication

Frequency Response: 20Hz to 22KHz ± 1dB

CMRR (MIC 1kHz): >75dB

THD+N: <0.05% (Channel to mix out)

Crosstalk (at 1kHz: Fader shutoff): >80dB

Noise (rms 22Hz to 22KHz): EIN-122dBu

Residual output noise: <-86dBu

L/R main mix noise: <-72dBu

Mono channel: XLR balanced, pin2 hot/pin3 cold, 2K ohm, sensitivity -60 to +10dB, phantom +48V; TRS balanced, tip hot/ring cold, 10K ohm, Sensitivity -20 to +20dB

Mono channel EQ: HF; shelving, +/-15dB, 12KHz. MF; shelving, +/-15dB, 2.5KHz. LF; shelving, +/-15dB, 80KHz

Stereo channel - 1/2: TRS unbalanced, tip hot, 20K ohm, sensitivity -20 to +20dBu

Stereo channel - 1/2 EQ: HF; shelving, +/-15dB, 12KHz. MF; shelving, +/-15dB, 2.5KHz. LF; shelving, +/-15dB, 80KHz

Stereo channel -3/4: 6.35 TRS unbalanced, tip hot, 10K ohm, Sensitivity -20 to +14dBu. 3.5mm TRRS unbalanced, tip/L, ring 1/R, ring2/GND, sleeve/output. 10Kohm, sensitivity -20 to +14dBu

DSP audio effects processor: 99 mode/24bit/48KHz, LED display

MP3 player/recorder: Audio decoding: MP3/WAV/APE/FLAC

LED display: USB 1.1 audio interface

Bluetooth: Compliant with bluetooth V5.1+BR+EDR+BLE specification

Max input power: 12V DC @ 2A 24W
