Switches
Altronics switches range offers pin to pin compatible components suitable as replacements for expensive brand name components. This includes toggle switches, push button tactile switches, relays and bases.
S4101
0.5A 12VDC SPST DIP PCB Mount Reed Relay
Fully sealed construction (immersion cleanable).
DIL pitch terminals.
$4.95
S4101A
0.5A 12VDC SPST DIP PCB Mount Reed Relay
Fully sealed construction (immersion cleanable). DIL pitch terminals.
$4.32
S4100A
0.5A 5VDC SPST DIP PCB Mount Reed Relay
Fully sealed construction (immersion cleanable). DIL pitch terminals.
$4.32
S3300
0-9 BCD Mini Thumbwheel Switch
Panel mount BCD coded units which slot together to produce a bank of switches. Each unit is engraved (white on black). Output is 8-4-2-1 weighting.Gold plated PCB tracks and connections. Cutout for one unit plus end caps 16 x 30mm. Allow further 8mm per unit. Can easily be ganged together to form any combination.
Pair of End Caps to Suit (S 3305).
$9.55
S3021
1 Pole 2-12 Position PCB Mount Rotary Switch
User Selectable Configuration. Each switch includes a toothed washer with a mating series of sockets in the switch housing to enable the switch to be configured to your specific requirement. 1P12T
$4.14
S5621
1.5A PCB Mount Auto Reset Circuit Breaker
Current Trip Rating: 1.5 Amp
All specifications at 25°C
Hold Current: 100% load indefinitely
Trip Current: Within 1 hr @ 175% load
Within 1 minute @ 200% load
Max. Voltage: 120V AC or 12V DC
Dimensions: 20.6H x 10.5L x 8.7W mm
$8.14
S3302
10 Position Decimal Mini Thumbwheel Switch
Panel mount Decimal coded units which slot together to produce a bank of switches. Each unit is engraved (white on black). Output is 8-4-2-1 weighting.Gold plated PCB tracks and connections. Cutout for one unit plus end caps 16 x 30mm. Allow further 8mm per unit. Can easily be ganged together to form any combination. Pair of End Caps to Suit (S 3305).
$8.86
S5598
100 Degree N.O. Thermal Circuit Breaker
Self resetting. Breaks at 100C. 10 amps 250V AC. Mounting hole centres 23.5mm. Contact surface 16mm. Normally Open Contact, Auto Reset.
$5.00
S4345
100A 12VDC High Current SPST Automotive Relay
Suitable for high current DC automotive applications. Not suitable for AC use. M6 bolt for contact load connection. 6.3mm spade terminals for contact coil connection.
NEW
$19.09
S4344
100A 24VDC High Current SPST Automotive Relay
Suitable for automotive applications such as alarms, driving lights, horns, fog lights etc.
$22.68
S5890
100A Surface Mount IP67 Waterproof Circuit Breaker
High current weatherproof circuit breakers with manual reset switch. M6 terminal bolts.
$45.41
S1160C
100V 1.0A Horizontal Float Switch
Fully immersible. Ideal for water tank systems such as rain or waste water management, activating boat bilge pumps etc. Can be used to control pumps or electric valves when liquid levels change.
$18.14
S4310
10A 12VDC DPDT Cradle Relay
10A DPDT relay. Cradle style featuring an in-built indicator. 12V DC coil.
$8.32
S4311
10A 12VDC DPDT PCB Mount Relay
10A DPDT relay. PCB mount style featuring an in-built indicator. 12V DC coil.
$8.32
S4160C
10A 12VDC SPDT PCB Mount Relay
10A heavy duty relay. Non-sealed type, suitable for flow soldering
$3.18
S4314
10A 240VAC DPDT Cradle Relay
10A DPDT relay. Cradle style featuring an in-built indicator. 240V AC coil.
$8.32
S4312
10A 24VDC DPDT Cradle Relay
10A DPDT relay. Cradle style featuring an in-built indicator. 24V DC coil.
$8.32
S4313
10A 24VDC DPDT PCB Mount Relay
10A DPDT relay. PCB mount style featuring an in-built indicator. 24V DC.
$8.32
S4162C
10A 24VDC SPDT PCB Mount Relay
24V 10A heavy duty relay. Non-sealed type, suitable for flow soldering
$3.18
S5590
10A 250V Switch Circuit Breaker
This 10A illuminated panel mount circuit breaker is ideal for use in automotive circuits (both 12V and 24V DC systems) where you require the function of a circuit breaker and ON/OFF switch in the same compact package.
$8.14
