3 Way HDMI 4K Switcher With Remote Control

SKU: A3087C
Switch between up to 5 AV sources with these professional 4K ready HDMI switchers. Each includes an IR remote control and receiver unit, which allows the switcher to be mounted behind the TV or inside a cabinet.
$49.05

All Prices Shown are (ex GST)
Bulk Pricing
ea $49.05
3+ $44.14
6+ $39.23
i h

Overview

Switch between 3 AV sources with these professional 4K ready HDMI switchers. Each includes an IR remote control and receiver unit, which allows the switcher to be mounted behind the TV or inside a cabinet. Supports 12-bit deep colour, 6.0Gbps high speed, full UltraHD 4K. Maximum distance between TV and HDMI source ˜25m.

Contains 1 x CR2025 battery in remote.

Please Note: Requires USB power supply either from a peripheral equipment source (TV/Amp) or an M 8861A

Package Contents
1× HDMI 3×1 Switcher
1× IR Receiver Cable
1× 5V USB Power Cable
1× Remote Control
1× User Manual



Features

  • HDCP 2.2/1.x and DVI 1.0 compliant
  • Support 18Gbps video bandwidth
  • HDR, HDR10, Dolby Vision and HLG are supported
  • Support video resolution up to 4K2K@50/60Hz YCbCr 4:4:4
  • Support 3D video format
  • Low power consumption
  • Support IR remote control and panel button control
  • Compact design for easy and flexible installation





Specifications

Technical

HDCP Compliance: HDCP 2.2/1.x

Video Bandwidth: 18Gbps

Video Resolution: Up to 4k2k@60Hz

Colour Depth: 8-bit (4K60Hz)

Colour Space: RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:4:4

HDMI Audio Formats: PCM2.0/5.1/7.1CH, Dolby 5.1, DTS 5.1, Dolby True HD, DTS-HD Master Audio

ESD Protection: Human body model—±8kV (Air-gap discharge) & ±4kV (Contact discharge)



Connection

Input Ports: 3×HDMI Type A (19-pin female) 1×IR IN [3.5mm Stereo Mini-jack]

Output Ports: 1×HDMI Type A (19-pin female)



Mechanical

Housing: Plastic Enclosure

Silkscreen Colour: Black

Dimensions: 87mm (W) × 59.5mm (D) × 19mm (H)

Weight: 60g

Power Supply: Input: 5V/1A

Power Consumption: 1.5W

Operation Temperature: 0°C ~ 40°C

Storage Temperature: -20°C ~ 60°C

Relative Humidity: 20~90% RH (non-condensing)







THIS PRODUCT CONTAINS A BUTTON BATTERY.

  • If swallowed, a lithium button battery can cause severe or fatal injuries within two hours.
  • Keep batteries out of reach of children.
  • If you suspect your child has swallowed or inserted a button battery, immediately call the 24-hour poisons information centre on 13 11 26 (within Australia) and seek medical attention.
button battery inside warning



Details

Products specifications

Warranty 12 Months
Audio Visual
Type HDMI Switchers

Warranty

WARRANTY

We offer 12 Months warranty on this product from its date of purchase. This is available from Altronics stores, online purchases or Altronics resellers. In accordance with our full warranty terms we will repair, replace or refund if goods you have purchased from us are defective.

30 DAY MONEY BACK GUARANTEE

Not withstanding our warranty policy, if you are dissatisfied with our goods or service you may return the goods within 30 days of our despatch date. Simply contact us for a return authorisation number and we will refund your purchase in full, less transport costs on receipt of goods. All returned goods must be in as sold condition including all packaging, instructions, invoices etc.

Downloads

.pdf
Instructions
PDF
