This Audio decoder can auto convert optical/coaxial channel (Support LPCM/PCM/RAW) input to 2.0 channel analog audio output, and supports decoding Dolby AC-3/DTS (included 5.1 RAW digital audio streaming).

5.1CH Digital Audio Converter

Name: 5.1CH Digital Audio Converter
SKU: A3195A
Price: 54.50 AUD
Availability: InStock

by: Dynalink

SKU: A3195A

This audio decoder/extractor can convert optical/coaxial channel (Support LPCM/PCM/RAW) input to 2.0 channel analog audio output, and supports decoding Dolby AC-3/DTS (included 5.1 RAW digital audio streaming).

$54.50

All Prices Shown are (ex GST)

Bulk Pricing

ea	$54.50
2+	$49.05
4+	$43.59

i h

Overview
Details
Warranty
Downloads

Overview

This Audio decoder can auto convert optical/coaxial channel (Support LPCM/PCM/RAW) input to 2.0 channel analog audio output, and supports decoding Dolby AC-3/DTS (included 5.1 RAW digital audio streaming). Compatible with the following network players; HDTV, Blu-ray DVD, Playstation, XBOX, DVD etc. It can be used to convert the digital output of a television into a standard stereo RCA for connection to amplifiers not fitted with digital audio inputs.

Dimensions: 81.7 x 78 x 21.2 mm

Included in Box:
1x Decoder
1x Micro USB Power Cable
1x User Manual

Please Note: A USB power supply is required. We recommend our M8861C USB wall charger (see accessories below)

Features:

Built-in high performance RTOS operating system and
audio decoder chip; supports DTS/AC-3
Super fast start time about 3 seconds
Auto Switch between optical and coaxial channel input
Auto decode AC-3/DTS (LPCM/PCM/RAW) input signal without any action
High compatibility
Small size
Metal case, Anti-interference
Headphone port output
Supports volume adjustment

Specifications:

Input:1 SPDIF Optical, 1 Coaxial

Output: L-OUT-R; 3.5mm Headphone port

Supported Audio formats: MP3, AC3, DTS, WAV, WMA, AAC, ALAC, FLAC, APE, OGG, M4A

Signal Noise ratio: 120dB

Stereo Isolation: 80dB (1kHz)

Channel Unbalance: 0dB

Sampling Rate: 32~192KHz

Bit Rate: 16~24 Bit

Response Frequency: 20Hz~20KHz +/-0.7dB

THD: 20Hz~20KHz 0.25-0.065%

THD+N: 1kHz 0.15%

Analog Output Level: 2.2V

Shell Dimension: 81.7 x 78 x 21.2mm

Weight: 110g

Ports: 1x Optical, 1x earphone jack, 1x L/R, 1x Optical

Working Voltage: 5V DC

Max power current: 200mA

Working temperature: 0-70°C

Working Humidity: 10%-80% RH (non-condensing)

Storage Temperature: -10-80°C

Storage Humidity: 5%%-90% RH (non-condensing)

Details

Products specifications

Warranty	12 Months
Professional Audio
Type	Signal Splitters

Warranty

WARRANTY

We offer 12 Months warranty on this product from its date of purchase. This is available from Altronics stores, online purchases or Altronics resellers. In accordance with our full warranty terms we will repair, replace or refund if goods you have purchased from us are defective.

30 DAY MONEY BACK GUARANTEE

Not withstanding our warranty policy, if you are dissatisfied with our goods or service you may return the goods within 30 days of our despatch date. Simply contact us for a return authorisation number and we will refund your purchase in full, less transport costs on receipt of goods. All returned goods must be in as sold condition including all packaging, instructions, invoices etc.

Downloads

Instructions

PDF
