HDMI & Infra-Red HDBaseT Cat5e/6 Extender UTP Balun

by: Dynalink
SKU: A3218B
Allows 1080p HDMI signals to be extended up to 100m from their source over a single Cat5e/6 cable, whilst retaining full high definition quality. Built in IR extender allows remote control of source devices.
Save $245.46 $299.09 $544.55

All Prices Shown are (ex GST)
Bulk Pricing
ea
$299.09 $544.55
2+
$299.09 $490.91
4+
$299.09 $436.36
i h

Overview

This long distance HDMI balun converter utilises HDBaseT technology and allows 4K HDMI signals to be extended up to 100m over a single Cat5e/6/7 cable, whilst retaining full quality. It also supports RS-232 control and LAN transmission, wide band IR and Power Over Ethernet (PoE).

Built in IR extender allows remote control of source devices. For Foxtel IQ, Austar and Mystar remotes use the A1075A target.

Includes transmitter, receiver, IR target, IR emitter & power supply.

Transmission:

Cat5e/Cat 6 - 100 metres max. Up to 1080 60Hz, 36bpp. Data rates lower than 5.3Gbps or below 225MHz TMDS clock.
Cat5e/Cat 6 - 70 metres max. Deep color up to 1080p/4Kx2K 60Hz, 48bpp. Data rates higher than 5.3Gbps or over 225MHz TMDS clock.
Cat6a/Cat 7 - 100 metres max. Deep color up to 1080p/4Kx2K 60Hz, 48bpp. Data rates higher than 5.3Gbps or over 225MHz TMDS clock.





Features:

  • 100m Range Max (depeding on cabling and resolution)
  • HDBaseT single UTP
  • HDCP compliant
  • Transmitter or receiver unit can be powered via PoE
  • Supports uncompressed HDMI signal
  • Supports 1080p @ 60Hz
  • Supports 4K x 2K @ 60Hz
  • Supports RS-232 signal bi-directional transmission, baud rate self-adaptive
  • Supports LAN transmission wide band IR

Details

Products specifications

Warranty 12 Months

Warranty

WARRANTY

We offer 12 Months warranty on this product from its date of purchase. This is available from Altronics stores, online purchases or Altronics resellers. In accordance with our full warranty terms we will repair, replace or refund if goods you have purchased from us are defective.

30 DAY MONEY BACK GUARANTEE

Not withstanding our warranty policy, if you are dissatisfied with our goods or service you may return the goods within 30 days of our despatch date. Simply contact us for a return authorisation number and we will refund your purchase in full, less transport costs on receipt of goods. All returned goods must be in as sold condition including all packaging, instructions, invoices etc.

Downloads

.pdf
Instructions
PDF
