With the help of this audio extractor you can extract audio signals from any HDMI compliant source to digital optical or analog stereo audio outputs.

HDMI 2.1 4K2K Audio Extractor

SKU: A3831B

With the help of this audio extractor you can extract audio signals from any HDMI compliant source to digital optical or analog stereo audio outputs.

Overview
Details
Warranty

Overview

This audio extractor allows users to extract audio signals from any HDMI compliant source or ARC-compatible TV to output analog stereo and digital S/PDIF audio, with a buffered HDMI video output. It supports data rates up to 48Gbps to comply with HDMI 2.1 and HDCP 2.3 requirements. It features both input and output of HDMI supporting video resolution up to 8K @ 60Hz. It includes several features for ease of integration, such as EDID management and cable equalization. It provides an easy solution for HDMI installations to send audio signals to a stereo audio or surround sound system.

Features

HDMI 2.1 and HDCP 2.3 compliant
Supports 48Gbps FRL and 18Gbps TMDS video bandwidth
Supports video resolution up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit
HDMI 2.1 protocols: VRR, ALLM, QMS, QFT, SBTM are supported
HDR, HDR 10, HDR 10+, Dolby Vision, HLG pass-through
LPCM 7.1CH, Dolby TrueHD, Atmos and DTS-HD Master, DTS:X Audio pass-through
HDMI input audio or TV ARC audio de-embedded to S/PDIF and L/R audio output
Supports CEC control from output devices to input sources
Advanced EDID management
Compact design for easy and flexible installation

Specifications

General

HDMI Compliance: HDMI 2.1

HDCP Compliance: HDCP 2.3

Video Bandwidth: 48Gbps FRL and 18Gbps TMDS

Video Resolution: Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit

Colour Depth: 8/10/12-bit

Colour Space: RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0

Audio Formats (HDMI IN/OUT): LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD

Audio Formats (AUDIO BREAKOUT): OPTICAL OUT: PCM 2.0CH, Dolby, DTS 5.1CH, L/R OUT: PCM 2.0CH

HDR: HDR, HDR 10, HDR 10+, Dolby Vision, HLG

ESD Protection: Human body model — ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

Connections

Input Ports: 1xHDMI Type A (19-pin female)

Control: 1 x SERVICE [USB Type C, Update port]

Output Ports:

1 x TV(ARC) OUT [HDMI Type A, 19-pin female]

1 x L/R [3.5mm Stereo mini-jack]

1 x OPTICAL [S/PDIF, female]

Mechanical

Housing: Metal Enclosure

Dimensions: 95W × 68D × 18Hmm

Weight: 178g

Power Supply: Input: AC 100-240V 50/60Hz, Output: DC 5V/1

Power Consumption: 4W (Max)

Operation Temperature: 0°C to 40°C

Storage Temperature: -20°C ~ 60°C

Relative Humidity: 20~90% RH (non-condensing)

Recommended HDMI Cable

Video Resolution (8K60):

HDMI Cable Type: Ultra HDMI 2.1 cable

HDMI Cable Length (HDMI IN / OUT): 2m~ 3m

Video Resolution (4K60):

HDMI Cable Type: HDMI 2.0 cable,

HDMI Cable Length (HDMI IN / OUT): 10m

Video Resolution 1080p:

HDMI Cable Type: HDMI cable

HDMI Cable Length (HDMI IN / OUT): 15m

Details

Products specifications

Warranty	12 Months
Audio Visual
Type	HDMI AV Converters
Weight	0

Warranty

WARRANTY

We offer 12 Months warranty on this product from its date of purchase. This is available from Altronics stores, online purchases or Altronics resellers. In accordance with our full warranty terms we will repair, replace or refund if goods you have purchased from us are defective.

30 DAY MONEY BACK GUARANTEE

Not withstanding our warranty policy, if you are dissatisfied with our goods or service you may return the goods within 30 days of our despatch date. Simply contact us for a return authorisation number and we will refund your purchase in full, less transport costs on receipt of goods. All returned goods must be in as sold condition including all packaging, instructions, invoices etc.
