HDMI Cat6 2 Way Splitter Balun Extender System

SKU: A4133
This UTP splitter extender can distribute 1 HDMI source signal to 2 display devices, supporting video resolution up to 4K@60Hz. The HDMI signal transmission distance can be extended up to 70m for 4K@30Hz, 60m for 4K@60Hz via a single CAT6 cable. It also supports advanced EDID management. Includes power supply.
$253.64

All Prices Shown are (ex GST)
Bulk Pricing
ea $253.64
2+ $227.27
4+ $204.55
i h

Overview

This UTP splitter extender can distribute 1 HDMI source signal to 2 display devices, supporting video resolution up to 4K@60Hz. They are designed with 1 HDMI input, 1 HDMI loop output and UTP outputs. The HDMI signal transmission distance can be extended up to 70m for 4K@30Hz, 60m for 4K@60Hz via a single CAT6 cable. It also supports advanced EDID management. Includes power supply.



Features:

  • HDCP 2.2 compliant

  • Video resolution is up to 4K@60Hz

  • The transmission distance is up to 70m for 4K@30Hz, 60m for 4K@60Hz via a single CAT6 cable

  • Support 1 HDMI input, 1 HDMI loop output and 2 CAT outputs.

  • Support HDMI audio formats: LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio

  • Support PoC function

  • Advanced EDID management

  • Compact design for easy and flexible installation





Specifications:

Technical:

HDMI Compliance: HDMI 2.0b

HDCP Compliance: HDCP 2.2

Video Bandwidth: 18Gbps

Video Resolution (Input & Output): 480i60, 576i50, 480p60, 576p50, 720p50/60, 1080i50/60, 1080p24/25/30/50/60; 640x480@60, 1024x768@60, 1280x768@60, 1280x800@60, 1280x1024@60, 1360x768@60, 1440x900@60, 1680x1050@60, 1920x1200@60RB; 3840x2160@24/25/30/50/60; 4096x2160@24/25/30/50/60;

Colour Depth: 8-bit,10-bit,12-bit(1080p@60Hz), 8-bit (4K2K@60Hz YUV4:4:4), 8-bit,10-bit,12-bit(4K2K@60Hz YCbCr 4:2:2/4:2:0)

Colour Space: RGB, YCbCr 4:4:4 / 4:2:2 YUV 4:2:0

Audio Formats: HDMI Loop Out: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD, Remote End: LPCM 2.0, Dolby 5.1, DD+7.1, DTS 5.1

HDR: HDR10, HDR10+, Dolby Vision, HLG

Transmission Distance: 70m for 4K@30Hz via a single CAT6 cable, 60m for 4K@60Hz via a single CAT6 cable

ESD Protection: IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)



Connection (Transmitter):

Input: 1 x HDMI IN [HDMI type A, 19-pin female]

Output: 1 x HDMI LOOP OUT [HDMI type A, 19-pin female], 2 x CAT OUT [RJ45]

Control: 1 x SERVICE [USB type C, update port]



Connection (Receiver):

Input: 1 x CAT IN [RJ45]

Output: 1 x HDMI OUT [HDMI type A, 19-pin female]



Mechanical:

Housing: Metal Enclosure

Colour: Black

Dimensions: Transmitter: 110W x 70D x 24.5Hmm, Receiver: 81W x 49D x 25Hmm

Weight: Transmitter: 241g; Receiver: 116g

Power Supply: DC 12V/1A

Power Consumption: 7.4W (Max)

Operating Temperature: 0°C ~ 40°C

Storage temperature: -20°C ~ 60°C

Operating Humidity: 20% ~ 80% RH (relative humidity, non-condensing)

Storage Humidity: 10% ~ 90% RH (relative humidity, non-condensing)
