Australian Made

6 Zone Universal Remote Alarm Wallplate

by: Redback
SKU: A4577
Designed to operate on 12 to 30VDC. This six input wall plate will sound a buzzer and illuminate a specific LED when an input is activated/triggered by a closing contact.
$140.91

All Prices Shown are (ex GST)
Bulk Pricing
ea $140.91
2+ $126.36
i h

Overview

Designed to operate on 12 to 30V DC. This six input wall plate will sound a buzzer and illuminate a specific LED when an input is activated/triggered by a closing contact. A Cancel button allows the buzzer to be switched off whilst the LED indicator remains on until the trigger is removed. The unit will Sound the buzzer anytime a new trigger is activated or a previous trigger is re-activated. May be used in numerous situations including security, fire alarm and access control systems.

All wall plates assembled by Altronics are supplied with two facia clip on covers. These are designed to match your current decor. Simply clip on the desired cover after installation.



Features:

  • Six monitored Inputs/triggers.
  • 12 to 30V DC powered.
  • Audible alert by buzzer.
  • Visual alert by LED (individual LED per trigger).
  • LEDs stay illuminated until trigger is deactivated.
  • Cancel switch to stop audible alert.
  • Pluggable terminal block for Triggers and DC in.




Designed & manufactured in Australia.
Since 1974 Redback public address products have been manufactured in Perth, Western Australia by Altronics. With over 50 years experience in the commercial audio industry, we offer consultants, installers and end users reliable products of high build quality with local product support. Read more about our Australian Made products





10 year warranty

Backed by an industry leading 10 Year Manufacturer Warranty.

Our Redback products have a long tried and tested history of bulletproof reliability. Altronics offers a 10 Year Warranty on all Australian Made Redback products. Our local in-house service department has all the know how to answer technical queries and provide timely service.

australian made

100% developed, designed & assembled in Australia.

Since 1974 Redback PA products have been manufactured in Perth, Western Australia by Altronics. With over 50 years experience in the commercial audio industry, we offer consultants, installers and end users reliable products of high build quality with local product support.

Details

Products specifications

Warranty 10 Years
Professional Audio
Type Evacuation Control Wallplates
