TL-WA901N 450Mbps Wireless N Access Point

by: TP-Link
SKU: D4278A
The TP-LINK Wireless N Access Point TL-WA901N is designed to establish or expand a scalable high-speed wireless N network or to connect an Ethernet-enabled device such as a game console, digital media adapter, printer, or network-attached storage device to a wireless network. The AP supports a host of different functions that makes your wireless networking experience more flexible than ever before.
$60.00

All Prices Shown are (ex GST)

Bulk Pricing
ea $60.00
i h

Overview

The TP-LINK Wireless N Access Point TL-WA901N is designed to establish or expand a scalable high-speed wireless N network or to connect an Ethernet-enabled device such as a game console, digital media adapter, printer, or network-attached storage device to a wireless network. The AP supports a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or any other application that you may wish to use.

Wireless N Speed & Range
Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through three antennas with smart antenna technology to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building. Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not!

Multiple Operating Modes - Easy to Build WLAN
Supports Client, Multi-SSID, Range Extender, and AP operation modes to enable various wireless applications to give users a more dynamic and comprehensive experience when using your AP. Multiple operating mode also helps you easily build wireless network for hard-to-wire locations or eliminating wireless dead zone.

Passive PoE Supported -More Flexible Deployment
The TL-WA901N is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.



Package Contents:

1 x Wireless Access Point TL-WA901N

3 x Detachable Omni Directional Antennas

1 x Power Supply Unit

1 x PoE Power Injector

1 x Quick Installation Guide

1 x RJ-45 Ethernet Cable





Specifications:



Hardware Features:

Interface : One 10/100M Ethernet Port(RJ45), Support Passive PoE

Button: WPS/Reset, Power On/Off

Power Consumption: 5.8W

External Power Supply: 9VDC/0.85A

Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Dimensions: 194.82W x 129.93D x 36.2H mm

Antenna Type: 3 Fixed Omni-Directional Antennas



Wireless Features:

Frequency: 2.4 GHz

Signal Rate: 450 Mbps at 2.4 GHz

Reception Sensitivity:

11g 54M: -76dBm

11n 20Mbps: -73dBm

11n 40Mbps: -70dBm

Transmit Power: <20dBm (CE)

Wireless Modes: Access Point, Range Extender, Client, Multi-SSID



Wireless Functions:

Enable/Disable Wireless Radio

WDS Bridge

WMM

Wireless Statistics

Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions

DHCP: Server, DHCP Client List

Quality of Service: WMM

Management: SNMP

Advanced Functions: Up to 30 meters PoE is supported



General:

System Requirements: Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,





Features:

  • 450Mbps wireless transmission rate brings smooth wireless N experience
  • Supports multiple operating modes: Access Point, Range Extender, Multi-SSID and Client modes
  • Easily setup a WPA-PSK/WPA2-PSK encrypted secure connection at a push of the WPS button
  • Up to 30 meters of flexible deployment with included Power over Ethernet Injector
