Power Supply Kit To Suit K5116 Amplifier

by: Silicon Chip Magazine
SKU: K5117
This is the recommended power supply for the K5116 Amplifier Module Kit.
$20.86

All Prices Shown are (ex GST)
Bulk Pricing
ea $20.86
5+ $18.86
i h

Overview

This is the recommended power supply for the K 5116 Amplifier Module Kit. The supply has been designed to use the M 5118 toroidal transformer. The secondary feeds a full-wave bridge rectifier and filter, formed by four 1N5404 diodes and two 4700µF 35V capacitors. The output is about ±25V unloaded and is suitable for powering one or two amplifier modules.

Important Note For Kit Buyers:

This product is supplied in component form and requires soldering, drilling, and assembly. We recommend users are familiar with at least basic electronic principles and have the ability to solder.

Details

Products specifications

Warranty 12 Months

Warranty

WARRANTY

We offer 12 Months warranty on this product from its date of purchase. This is available from Altronics stores, online purchases or Altronics resellers. In accordance with our full warranty terms we will repair, replace or refund if goods you have purchased from us are defective.

30 DAY MONEY BACK GUARANTEE

Not withstanding our warranty policy, if you are dissatisfied with our goods or service you may return the goods within 30 days of our despatch date. Simply contact us for a return authorisation number and we will refund your purchase in full, less transport costs on receipt of goods. All returned goods must be in as sold condition including all packaging, instructions, invoices etc.

Accessories
(SC Dec 2004) Extremely simple amplifier kit designed to be easy enough for beginners to assemble. Delivers 20W RMS and is suitable for small hi-fi applications or a PC sound system.
K5116

20W Amplifier Module Kit

Extremely simple amplifier kit designed to be easy enough for beginners to assemble. Delivers 20W RMS and is suitable for small hi-fi applications or a PC sound system.(Silicon Chip Magazine Dec 2004).
$36.59
