7VA 15+15V PCB Transformer

by: Powertran
SKU: M7130A
Manufactured using very high quality grain oriented silicon steel. This results in a compact, high performance, high output transformer.
$14.32

All Prices Shown are (ex GST)
Bulk Pricing
ea $14.32
4+ $12.68
10+ $11.36
i h

Overview

Manufactured using very high quality grain oriented silicon steel. This results in a compact, high performance, high output transformer. Each transformer has been tested to verify conformance to AS/NZS 61558.2-6 standard, and is rated to operate at 230V~ or 240V~ @ 50Hz.

Note: Must be used with a standard 100mA external AC fuse.





Specifications:



Sec. V: 15+15

Sec. Parallel: 0.466A

Sec. Series: 0.233A

Primary voltage: 230V AC or 240V AC @ 50Hz

Total VA rating: 7VA

Insulation: Class B (130°C)

Magnetising current: <30mA

Temperature rise: <65°C

Recommended AC Fuse: 100mA

Regulation: ~ 11%

Weight: ~ 265g

PCB hole size: 1mm

Thermal Fuse: Internal 115°C

Standard AS/NZS 61558.2.6 Certified
