HDR-30-12 24W 12VDC 2A DIN Rail Switchmode Power Supply

by: Mean Well
SKU: M8392
The Mean Well HDR-30-12 is a 24W DIN rail mountable power supply with an output voltage of 12V. The ultra-slim design is ideal for lower current DC power applications in a standardised DIN rail housing to suit mounting to asymmetrical “G” or 35mm top hat type DIN rails. Each unit measures only 90mm high and is supplied in 35mm and 52.5mm widths.
$42.32

All Prices Shown are (ex GST)
Bulk Pricing
ea $42.32
2+ $39.95
4+ $38.68
i h

Overview

The Mean Well HDR-30-12 is a 24W DIN rail mountable power supply with an output voltage of 12V. The ultra-slim design is ideal for lower current DC power applications in a standardised DIN rail housing to suit mounting to asymmetrical “G” or 35mm top hat type DIN rails. Each unit measures only 90mm high and is supplied in 35mm and 52.5mm widths.





Specifications:



Output: 2A

Rated Wattage: 24W

Inrush Current: 25A

Efficiency: 88%

Input Range: 85-264V AC, 120-370V DC

Input Frequency: 47-63Hz

Warranty: 3 years

Weight: 120g

Dimensions: 35 x 90 x 54.5mm



Features:

  • 24W power output at 12V DC (2A)
  • Ultra slim design with 35 or 52.5mm widths
  • Universal AC input
  • Protections: short circuit, overload, over voltage
  • Cooling by free air convection
  • Suits TS-35/7.5 or 15 DIN rail
  • LED power indicator

Details

Products specifications

Warranty 3 Years

Warranty

WARRANTY

We offer 3 Years warranty on this product from its date of purchase. This is available from Altronics stores, online purchases or Altronics resellers. In accordance with our full warranty terms we will repair, replace or refund if goods you have purchased from us are defective.

30 DAY MONEY BACK GUARANTEE

Not withstanding our warranty policy, if you are dissatisfied with our goods or service you may return the goods within 30 days of our despatch date. Simply contact us for a return authorisation number and we will refund your purchase in full, less transport costs on receipt of goods. All returned goods must be in as sold condition including all packaging, instructions, invoices etc.

Downloads

.pdf
Data Sheet
PDF
