12/24V MPPT Solar Charge Controller 20A

SKU: N2024
These compact regulators utilise Maximum Power Point Tracking (MPPT) circuitry to provide up to 20% additional charge energy than conventional regulators. This essentially allows you to get more power from your existing panels, or alternatively reduce the overall required panel wattage for new systems. It is suitable for permanent installations of lead acid and gel battery solar panel systems.
Save $54.55 $90.00 $144.55

All Prices Shown are (ex GST)
Bulk Pricing
ea
$90.00 $144.55
2+
$90.00 $131.82
4+
$90.00 $117.27
i h

Overview

These compact regulators utilise Maximum Power Point Tracking (MPPT) circuitry to provide up to 20% additional charge energy than conventional regulators. This essentially allows you to get more power from your existing panels, or alternatively reduce the overall required panel wattage for new systems. It is suitable for permanent installations of lead acid and gel battery solar panel systems. LEDs are provided to indicate working status - solar charge ON, load ON and battery level. Suitable for 12V or 24V systems, the charger automatically detects the connected battery voltage. Ideally suited to vehicles and simple remote power systems such as pumping stations, electric fences, remote lighting, marine applications etc.





Specifications:



Max charge/load current 20A

12V low voltage dis/reconnect 10.8V

24V low voltage dis/reconnect 216V

No load current: <10mA

Max solar input voltage <50V

Terminal wire size 10AWG

Operating temperature: -35°C to +55°C

Dimensions (mm) 131 x 100 x 34



Features:

  • Utilises Maximum Power Point Tracking (MPPT) circuitry
  • USB 1A charging output
  • Suits lead acid or gel battery systems
  • Charge indicators
  • Reverse polarity protection
  • Short circuit and overload protection
  • Over temperature protection

Details

Products specifications

Warranty 12 Months
Car, Caravan & 4WD
Type MPPT Controllers
