12/24V MPPT Solar Charge Controller 40A

SKU: N2026A
This dual input design connects to a solar panel and your cars alternator (12 or 24V) to provide 3 stage charging for secondary batteries such as those used in campers, caravans and trades service vans/trailers. It is compatible with the latest smart alternators and start/stop systems found in modern vehicles.
$217.27

All Prices Shown are (ex GST)
Bulk Pricing
ea $217.27
2+ $195.45
4+ $177.27
i h

Overview

This 40A Input 12/24V Solar MPPT Charger allows you to get more power from your existing panels, or alternatively reduce the overall required panel wattage for new systems. The charger utilises Maximum Power Point Tracking (MPPT) circuitry to provide up to 20% additional charge energy than conventional regulators. It is suitable for permanent installations of lead acid, gel battery and lithium chemistry solar panel systems. LEDs are provided to indicate working status - solar charge ON, load ON and battery level. Suitable for 12V or 24V systems, the charger automatically detects the connected battery voltage. Ideally suited to vehicles and simple remote power systems such as pumping stations, electric fences, remote lighting, marine applications etc.

Warning: Do not set up using a common earth wiring configuration. Cabling should be as per the user manual with both positive and negative of battery, solar panel, and load each wired straight to the solar regulator. Failing this will damage your battery and load.





Specifications:



Rated charge current: 40A

System rated voltage: 12/24V Auto recognized

Voltage range: 8V-32V

Max open voltage of solar panel: 100V

Max solar input: 12V 520W/24V 1040W

Battery Type: Sealed, Gel, Flooded Lead, Acid, LiFePO4, Li(NiCoMn)O2 Battery

Equalized charging voltage: Maintenance-free lead-acid battery: 14.6V, GEL: No;Lead-acid Flooded battery: 14.8V

Absorption charging voltage: Maintenance-free lead-acid battery: 14.6V, GEL: 14.2V;Lead-acid Flooded battery: 14.6V

Float charging voltage: Maintenance-free lead-acid battery, GEL, Lead-acid Flooded battery: 13.8V

LVR: Maintenance-free lead-acid battery, GEL, Lead-acid Flooded battery: 12.6V

LVD: Maintenance-free lead-acid battery, GEL, Lead-acid Flooded battery: 10.8V

Static loss: =45mA/12V, =37mA/24V

HVD: 16V

Duration of absorption charging: 2hrs

Duration of Equalized charging: 2hrs

Light control voltage: 5V

Temperature compensation coefficient: -4mV/°C 2V (25°C)

Discharge loop voltage drop: =0.2V

LCD temperature: -20°C - 70°C

Operating temperature: -20°C - 55°C

Storage temperature: 30°C - 80°C

Working humidity: =90% Condensation

Protection class: IP30

Grounded type: Positive grounded

Dimensions: 215.5 x 174 x 65mm

Hole size for installation: 164 x 160mm

Aperture for installation: Ø5mm

Terminal wiring: 16mm/5AWG

Weight: 1.125kg



Features:

  • Advanced MPPT technology
  • Multi-chemistry design suits Sealed, Gel, Flooded Lead, Acid, LiFePO4, Li(NiCoMn)O2 type batteries
  • Super fast tracking speed whilst ensuring efficiency
  • Accurate Identification
  • Reliable maximum input power
  • 12/24V automatic voltage identification
  • LCD display screen
  • Various load controls
  • Battery temperature compensation
  • Power statistics recording function
  • Supports PC monitor, external display unit and other peripherals, real-time date view and parameter setting function
  • Suits lead acid, gel type and lithium chemistry batteries
