18 Pin (0.3") DIL Machined Pin IC Socket

by: Oupiin
SKU: P0536
Quality Oupiin brand 8004 series, 18 pin DIL IC socket with machined pins and gold plated beryllium copper contacts. Standard 2.54mm (0.1") pin spacing, 7.62 (0.3") pitch.
$2.55

All Prices Shown are (ex GST)
Bulk Pricing
ea $2.55
10+ $2.32
25+ $2.00
i h

Overview

Quality Oupiin brand 8004 series, 18 pin DIL IC socket with machined pins and gold plated beryllium copper contacts. Standard 2.54mm (0.1") pin spacing, 7.62 (0.3") pitch.



Dimensions:

A: 22.84

B: 20.32

C: 10.14

D: 7.62





Specifications:



Contact Resistance: 30M Ohms Max @ DC 100mA

Insulation Resistance: 1000M Ohms Min @ DC 250V

Current Rating: 1 Amp

Dielectric Voltage: AC 500V for 1 Minute

Operating Temp: -55° to 105° C

Gold Plated Beryllium Copper Contacts



Details

Products specifications

Warranty 12 Months
Connectors
Type Machined Pin IC Sockets
