32 Pin Female Rows A&C PCB Mount DIN 41612

by: Oupiin
SKU: P4932
Moulded glass-filled polyester connectors to DIN 41612 with gold contacts. The plug moulding houses single piece 90 deg. Angled pins on a 0.1 inch pitch between rows, allowing horizontal mounting on Eurocards whilst the mating sockets have flow solder (4mm) spills.
$4.95

All Prices Shown are (ex GST)
Bulk Pricing
ea $4.95
4+ $4.45
10+ $3.95
i h

Overview

Moulded glass-filled polyester connectors to DIN 41612 with gold-finished contacts. The plug moulding houses single piece 90° angled pins on a 0.1 inch pitch between rows, allowing horizontal mounting on Eurocards whilst the mating sockets have flow solder (4mm) spills. “B” (two row) and “C” (three row) types are available. They also feature integral moulded polarising tabs. Right angle connectors are male gender and straight pin connectors are female.





Specifications:



Proof Voltage: 1000V DC min

Max. Current Per Contact: 1.5A

Contact Resistance: 15M Ohm max

Insulation Resistance: 10¹² Ohms min

Temperature Range: -55° C to +125° C

Details

Products specifications

Warranty 12 Months
Connectors
Type DIN 41612 Connectors
Pins 32 Pin
Pitch 2.54mm
