75A 600V Black PowerPole Style High Current DC Anderson Plug

SKU: P7818B
Genuine Anderson Power DC 600V connector. PP75
$5.00

All Prices Shown are (ex GST)

Bulk Pricing
ea $5.00
10+ $4.50
25+ $4.09
i h

Overview

Anderson PowerPole style DC 600V connector (not genuine). As used in automotive and industrial applications. Can be dovetailed together for multi-pole connectors. 75A rated. Sold individually.

Supplied with connector housing and crimp lug.





Specifications:



Cable Entry: 3.2mm.

Max Insulation Diameter: 11mm

Rated current: 75A

Rated voltage: 600V

Insulation Resistance: 5000MΩ

Average contact Resistance(micro-ohms):<180 1-5.

Voltage Proof: 2200V(DC)

Life Without load(Contact/Disconnect Cycles):To 10000

Life With Load (Hot Plug 250 Cycles&120V): 50A

Flammability: UL94 V-0

Contact Barrel Wire Size(AWG):6~12AWG

Connector holding force(LBF):250N Min

Environment Temperatures:-20℃ to 125℃

Details

Products specifications

Warranty 12 Months
Connectors
Type Anderson PowerPole Style Plugs
