5k 5mm Side Adjust Trimpot

SKU: R2491B
A single turn 5k Ohm side adjustment trimming potentiometer
$1.41

All Prices Shown are (ex GST)
Bulk Pricing
ea $1.41
10+ $1.00
25+ $0.86
i h

Overview

Side Adjust Trimpot. 5mm. Single Vertical.



Specifications:

Norminal resistance: 5K
Resistance tolerance: 10%
Residual resistance: max 5% of nominal resistance. Bbu under 30 Ohms
Resistance taper: Linear
Rated power: 0.1W
Operating voltage: 50V max.
Rotational life: max ±15% change in resistance after 100 unloaded rotations.
Load life: max ±15% change in resistance after 3 hours loaded.
Rotational angle: 200° (±20°)
Rotational torque: 600-300g.cm
Stop end strength: 500g.cm minimum
Operating temperature: -5°C to 40°C
Temperature characteristic: resistance change within +5-30% after 5 hours at 70°C
Humidity characteristics: maximum resistance change within 20% after 350 hours loaded at 40°C and RH 90%
Soldering temperature: 250°C at 2 seconds

Details

Products specifications

Warranty 12 Months
Components
Turns Single Turn
Type Trimming Potentiometers
