SPDT Mom. 90 Deg. PCB Sub-Mini Pushbutton Switch

Name: SPDT Mom. 90 Deg. PCB Sub-Mini Pushbutton Switch
SKU: S1495
Price: 3.86 AUD
Availability: InStock

by: Salecom

SKU: S1495

SPDT configutation momentary push button switch. Sub miniature sizing. PCB mountable right angle type.

$3.86

All Prices Shown are (ex GST)

Bulk Pricing

ea	$3.86
10+	$3.50
40+	$3.09

i h

Overview
Details
Warranty

Overview

The Salecom range of miniature and sub-miniature switches are pin for pin compatible with several other leading brands but at a fraction of the cost. Already many major manufacturers across Australia use the Salecom brand in preference to the more expensive makes. Salecom offers excellent value for money. Typically Salecom switches are reliable for up to 50,000 switching operations at full ratings.

Specifications:

Contact Rating: 20mA @ 20V max. AC / DC

Electrical Life: 50,000 cycles at full load

Contact Resistance: 20m Ohm max. initial at 24V DC @ 100mA

Insulation Resistance: 1,000 M Ohm min.

Dielectric Strength: 1000V RMS at Sea Level

Operating Temperature: -30°C to 85°C

Bushing: Glass Filled Nylon 66

Case: Glass Filled Nylon 66

Contact & Terminals: Copper Alloy with Gold Plate over Nickel Plate

Details

Products specifications

Warranty	12 Months
Switches
Action	Momentary
Contacts	SPDT
Connection	PCB Mount
Type	Panel Mount Switches
