24VDC 30A SPST Fused Automotive Relay

SKU: S4332
Suitable for automotive applications such as alarms, lights, etc. Fitted with 30A blade fuse.
$10.45

All Prices Shown are (ex GST)

Bulk Pricing
ea $10.45
10+ $9.32
40+ $8.45
i h

Overview

30A SPST relay. 24V DC coil. Fitted with 30A blade fuse. Suitable for automotive applications such as alarms, lights, etc.

Note: Not suitable for AC use.



Specifications:



Max Switching Voltage DC: 75V

Max Switching Current DC: 30A

Max Switching Power DC: 420W

Contact Material: Silver tin dioxide

Coil Resistance: 320Ω

Max Coil Power: 1.8W

Insulation Resistance: >100MΩ @ 500V DC

Dielectric Strength (for 1 min):

500V AC between open contacts

750V AC between coil & contact

Electrical Life: 100,000 operations

Mechanical Life: 10 million operations

Dimensions: 25.4W x 33.3L x 21.2H mm (excluding fuse and tab)

Details

Products specifications

Warranty 12 Months
Switches
Type Automotive
Contacts SPST
