This 5A 12VDC SPST Cradle Relay acts like a simple on-off switch for a single electrical circuit. The cradle provides a secure mounting point and connection terminals for the relay, making it useful in applications like automotive electrical systems.
Specifications:
Resistive Load: 12A/250V AC, 300V DC
Resistive switching power: 3000VA, 360W
Electrical Life: ≥100,000 cycles
Initial contact resistance: ≤50mΩ
Insulation resistance: ≤100mΩ (500V DC)
Coil power: DC: About 0.53W. AC: About 0.9VA
Contact release time: AC: ≤20ms. DC: ≤10ms. Diode: ≤20ms
Operating temperature: -40°C to 70°C
Impact resistance: Stability 98m/S². Strength 980m/S²
Installation: Plug-in Installation
Weight: ~20g
Power frequency withstand voltage:
Between contacts of the same pole: 1,500V AC, 1min
Between contacts of the opposite pole: 3,000V AC, 1min
Between contact and coil: 3,000V AC, 1min
Materials:
Contact: SIlver Alloy
Body: PC
Base: PBT
