5A 24VDC SPST Cradle Relay

SKU: SA4195
This 5A 24VDC SPST Cradle Relay acts like a simple on-off switch for a single electrical circuit, making it useful in applications like automotive electrical systems.
$13.59

All Prices Shown are (ex GST)

Bulk Pricing
ea $13.59
10+ $12.73
40+ $10.91
i h

Overview

This 5A 24VDC SPST Cradle Relay acts like a simple on-off switch for a single electrical circuit. The cradle provides a secure mounting point and connection terminals for the relay, making it useful in applications like automotive electrical systems.



Specifications:

Resistive Load: 12A/250V AC, 300V DC

Resistive switching power: 3000VA, 360W

Electrical Life: ≥100,000 cycles

Initial contact resistance: ≤50mΩ

Insulation resistance: ≤100mΩ (500V DC)

Coil power: DC: About 0.53W. AC: About 0.9VA

Contact release time: AC: ≤20ms. DC: ≤10ms. Diode: ≤20ms

Operating temperature: -40°C to 70°C

Impact resistance: Stability 98m/S². Strength 980m/S²

Installation: Plug-in Installation

Weight: ~20g



Power frequency withstand voltage:

Between contacts of the same pole: 1,500V AC, 1min

Between contacts of the opposite pole: 3,000V AC, 1min

Between contact and coil: 3,000V AC, 1min



Materials:

Contact: SIlver Alloy

Body: PC

Base: PBT



Details

Products specifications

Warranty 12 Months
Switches
Type Cradle
Contacts SPST
