CAN-BUS Shield for Arduino

SKU: Z6426
The onboard BUS control chip can realize the data control on the CAN bus and data communication between devices.
$21.77

All Prices Shown are (ex GST)
Bulk Pricing
ea $21.77
2+ $19.77
4+ $17.50
i h

Overview

This CAN-BUS Shield has been designed to be used with Arduino controllers. The onboard BUS control chip can realise the data control on the CAN bus and data communication between devices. It is compatible with the Arduino UNO standard interface; can be perfectly adapted to the main control boards such as Arduino UNO and Leonardo. The shield provides a DB9 connector, so you can choose the interface according to your needs. It also comes with MicroSD card slot, so you can directly insert MicroSD card to store data. A variety of expansion interfaces allow users to get more convenience in the DIY process.







Specifications:



Operating Voltage: DC5V

Chip: MCP2515

Dimensions: 66 x 54 x 28mm

Weight: 24g

Environmental Attribute: ROHS



Features:

  • Supports standard frame, extended frame of transmission and reception; support two receiving methods: Polling and interrupt
  • Provide various interfaces, such as U-Art, I2C, DB9 connector, etc.
  • Support SD card data storage
  • Support power supply via Arduino motherboard or DB9 connector (Pin 9 = VIN (voltage in), Pin 6 = GND)

Details

Products specifications

Warranty 12 Months
