Converts two-channel balanced/unbalanced analog audio into Dante 2CH digital audio, then transmits the audio to the receiving end through network (Dante).

2Ch Input to Dante Output Adapter

Name: 2Ch Input to Dante Output Adapter
SKU: A3174
Price: 244.55 AUD
Availability: InStock

by: Redback

SKU: A3174

Converts two-channel balanced/unbalanced analog audio into Dante 2CH digital audio, then transmits the audio to the receiving end through network (Dante).

$244.55

All Prices Shown are (ex GST)

Bulk Pricing

ea	$244.55
2+	$227.27
2+	$195.45

i h

Overview
Details
Warranty
Downloads

Overview

This Dante 2CH screw terminal Input Adapter is an audio transmitter based on the Dante Ultimo 2x2 solution. It converts two-channel balanced/unbalanced analog audio into Dante 2CH digital audio, then transmits the audio to the receiving end through network (Dante). Analog audio input supports 5-level sensitivity adjustment. The adapter supports local USB-C port power supply and PoE function.

Features:

Two-channel analog audio to Dante 2CH digital audio
Balanced/unbalanced screw terminal analog audio input
Dante audio sampling rate supports 44.1/48/88.2/96KHz@24bit
Dante audio delay supports 1/2/5ms (configurable)
Analog audio input supports 5-level sensitivity adjustment (+24dBu, +4dBu, 0dBu, 0dBv, -10dBv)
Compatible with AES67 input and output.
Supports local USB-C port power supply and PoE function (Class 0 802.3af PoE)
Compact design for easy and flexible installation

Specifications:

Technical

Input: Two-channel balanced/unbalanced analog audio

Output: Dante® 2CH digital audio

Control Method: Dante® Controller

Network Bandwidth: 100Mbps

Audio Latency: Configurable Dante® device latency (Supports 1, 2 or 5ms configurable using Dante® Controller)

Transmission Distance: 100m (CAT6/6A/7)

ESD Protection: IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

Audio Formats:

LINE IN [Analog audio input, Balanced/unbalanced

2CH, Max input level +24dBu]

DANTE OUT [Digital audio output, PCM 2CH

44.1K-96KHz 16/24bit]

Audio Parameters (Line In)

Input Impedance: 20k Ohm balanced 10k, Ohm unbalanced

Line Input Level (Maximum): +24dBu (12.28Vrms) @ balanced audio, +18dBu (6.15Vrms) @ unbalanced audio

Frequency Response: 20Hz to 20kHz (-/+0.5dB)

Dynamic Range: >100dB@0dBu, 1kHzA-weighted

Audio S/N Ratio: >100dB@0dBu, 1kHzA-weighted

Audio THD+N: < 0.01% at +4dBu, 1KHz

Audio Output Sync Delay: <10ms

Connection

Input port: 2x CH1/CH2 LINE IN [6pin-3.5mm phoenix connector], 1x POWER [USB-C power and firmware update port,, 12-pin female]

Output port: 1x DANTE [RJ45 connector, PoE]

Others: 1x RESET button [System reboot button], 2x SENSITIVITY knob [5-level dip switch

Mechanical

Housing: Metal Enclosure

Colour: Black

Dimensions: 115W x 40D x 28Hmm

Weight: 94g

Power Supply: USB input: 5V/500mA, PoE input: PoE IEEE802.3af Class 0

Power Consumption: 2W (Max)

Operating Temperature: 0°C ~ 40°C

Storage Temperature: -20°C ~ 60°C

Operating Humidity: 20% ~ 80% RH (relative humidity, non-condensing)

Storage Humidity: 10% ~ 90% RH (relative humidity, non-condensing

Details

Products specifications

Warranty	12 Months
Professional Audio
Type	Dante Products

Warranty

WARRANTY

We offer 12 Months warranty on this product from its date of purchase. This is available from Altronics stores, online purchases or Altronics resellers. In accordance with our full warranty terms we will repair, replace or refund if goods you have purchased from us are defective.

30 DAY MONEY BACK GUARANTEE

Not withstanding our warranty policy, if you are dissatisfied with our goods or service you may return the goods within 30 days of our despatch date. Simply contact us for a return authorisation number and we will refund your purchase in full, less transport costs on receipt of goods. All returned goods must be in as sold condition including all packaging, instructions, invoices etc.

Downloads

Instructions

PDF

Brochure

PDF
